High Speed Plastic Profile WPC CPVC Opvc PE PVC PPR UPVC Water/Drainage Pipe Window/Door Making Extrusion Double Screw Single Screw Extruder Machine

• Overview
• Detailed Photos
• Product Description
• Product Parameters
• Why choose us?
• FAQ

Overview

Basic Info.

Model NO.	PE 63
Screw No.	Single-screw
Automation	Automatic
Computerized	Computerized
Certification	CE, ISO9001:2008, QS
Customized	Customized
Condition	New
After-sales Service	12 Months
Temperature Controller	Omron or Rkc
Raw Material	PE Granules
Pipe Application	Water Supply and Drainage, Gas S
DC Speed Controller	Eurothem
Main Electrics	Siemens or Schneider
Pipe Diameter	20-63mm
Screw Design	Single-Screw for PE PPR, Double for PVC
Transport Package	Film Package or Wood Case Package
Specification	16-630mm for pvc pipe machine
Trademark	XINTING
Origin	Zhangjiagang China
HS Code	84772090
Production Capacity	10 Lines Per Year

Packaging & Delivery

Package Size1600.00cm * 400.00cm * 400.00cm Package Gross Weight16000.000kg

Product Description

Equipment list of PVC pipe extrusion line

Our advantages 1.20+ years plastic machine factory and we have 20000 square meters standard workshop 2.15+ years experience engineer for the plastic machine, They can provide you with customized services 3.15+ years experience After-sales team, They have debugged and repaired 100+ production lines. 4.18 hours online sales staff, They can answer your questions within 6 hours

Q: Your company is a transactional company or an industrial manufacture factory?A: We are an industrial manufacture factory which locates in Zhangjiagang city.Q: All of your products are made by your self or compacted via purchasing the others?A: We have independent technical team who focus on making machines, all the products are made by our technical team.Q: What is the ability of your factory?A: About 100 lines per month.Q: Do you have any other services about your products?A: We have a lot of experience on making projects and specifications for our clients, also we have a fixed service system.Q: How do you make the quotation for clients? A: The price depends on quality and performance but the clients should be satisfied first.

High Speed Plastic profile WPC CPVC OPVC PE PVC PPR UPVC Water/Drainage Pipe WINDOW/DOOR Making Extrusion DOUBLE SCREW SINGLE SCREW EXTRUDER Machine

Detailed Photos

Product Description

Highest Speed PPR Pipe Making Machine 20mm-63mm
HDPE / PE PPR Pipe is mainly used for in the area of agricultural water supply system, architectural water supply and draiange system, pavement of cables and gas supply etc.

The basic HDPE / PE Pipe Production Line consists of
1. Color Mixer ( for raw material preparation)
2. Single Screw Extruder
3. Extrusion Mold
4. Vacuum Tank
5. Cooling Tank
6. Haul Off Machine
7. Cutting Machine
8. Stacker ( for 110mm upto 1200mm)
9. Winding Machine ( for pipe diameter 16-63mm and 75-110mm)
10. Shredder and Crusher ( for waste pipe treatment, the recycled PE material could produce pipe again.)

Our HDPE / PE PPR Pipe Production Line has the features as below:
1. Good components: Siemens Beide main motor, ABB inverter, Eurotherm DC regulator, Siemens & Schneider low voltage electrics, Omron temperature controller

2. Good design and good outlook: We design the machine for easier operation and stable performance. The haul off machine and cutter is fully closed for safety purpose. Planetary socket is using in some machines for wire connection.

3. Our engineers and technicians have more than 10 years experince, they know pipe machine well and make good pipe machine.

Product Parameters

PE PPR PIPE MAKING MACHINE
Technical parameters Highest Speed PPR Pipe Making Machine 20mm-63mm:

Model	Pipe diameter	Extruder.	Max. output (kg/h)	Total installed power (KW)	Lenght of production line(m)
PE-32	Φ4-32	SJ-45/30 SJ-25/25	30-120	45	28
PE-63	Φ20-63	SJ-60/33 SJ-25/25	120-220	100	36
PE-110	Φ20-110	SJ-65/33 SJ-30/25	150-250	120	39
PE-160	Φ63-160	SJ-65/33 SJ-30/25	120-270	150	43
PE-250	Φ75-250	SJ-75/33 SJ-30/25	280-400	230	45
PE-450	Φ110-450	SJ-90/33 SJ-30/25	450-600	350	65
PE-630	Φ315-630	SJ-120/33 SJ-30/25	700-950	550	75
PE-800	Φ400-800	SJ-90/33 SJ-105/33	800-1200	700	75

PVC PIPE MAKING MACHINE

Model/data	Pipe diameter	Extruder model	Speed	Max capacity
PVC63	16-63mm	SZ51/105	10-20m/min	120kg/h
PVC160	75-200mm	SZ65/132	1.5-5m/min	260kg/h
PVC400	200-400mm	SZ80/156	0.5-5m/min	400kg/h
PVC630	400-630mm	SZ92/188	0.1-4m/min	650kg/h

Compulsory devices
1		Material charge		1 set
2		Conical twin screw extruder SJ-65/132, 80/156, 92/188		1 set
3		Pipe die head		16-800mm, 1 set or several sets
4		Vacuum calibrating tank		1 set or several sets
5		Water spraying cooling tank		1 set or several sets
6		2-3-4-6-8-10-12 caterpillars hauling off machine		1 set
7		Saw cutting machine or planetary cutting machine		1 set
8		Pipe stacker-6000mm length		1 set
9		Electrical cabinet(ABB, Omron, RKC, etc)		1 set
10		Spare parts		1 set
Optional Devices
1		High speed hot and cold mixer		1 set
2		Plastic crusher		1 set
3		Plastic pulverizer		1 set
4		Industrial water chiller		1 set
5		Air compressor		1 set
6		Thermocontroller for die head		1 set
7		Ink jet printer		1 set
Payment, delivery and after sales services
1	Payment terms		30% for prepayment by T/T, 70% for balanced payment by T/T, or L/C can be acceptable
2	Delivery time		60 days after receipt of prepayment
3	Packing method		Wooden cases/pallets with stretching films
4	Guaranteed time		18 months for mechanical parts, 12 months for electrical parts
5	After sale service		Send 1-2 engineers to customers' factory to help them install, test the machine, and train their workers. This is chargeable
